Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | RFDIP | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Device Type Classification | Diplexer | |
| Low/High Frequency Bands | 1.565GHz ~ 1.585GHz / 2.4GHz ~ 2.5GHz | |
| Low Frequency Attenuation dB | - | |
| High Frequency Attenuation dB | 30.00dB / - | |
| Band-Specific Return Loss | 10.0dB / 10.0dB | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 1008 (2520 Metric), 9 PC Pad |
Description
Facilitates a maximum output current level set as 1.565GHz ~ 1.585GHz / 2.4GHz ~ 2.5GHz. Operates within 1.565GHz ~ 1.585GHz / 2.4GHz ~ 2.5GHz low and high frequency bands for various applications. Provides an attenuation of 30.00dB / - dB within the high frequency range for efficient signal handling. Mounting configuration Surface Mount for structural stability. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 1008 (2520 Metric), 9 PC Pad that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Return loss in the specified low/high frequency band 10.0dB / 10.0dB for RF performance. Classification series for the product or component RFDIP. Type classification Diplexer for specifications.
