Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | WR-PHD | |
| IC Encapsulation Type | Bag | |
| Availability Status | Active | |
| Switch Position Options | 32 | |
| Component Spacing Distance | 0.100" (2.54mm) | |
| Grid Row Count | 1 | |
| Row Pin Gap | - | |
| Complete Pin Dimension | 1.436" (36.480mm) | |
| Mating Post Length | 0.118" (3.000mm) | |
| Stacked Assembly Height | 1.200" (30.480mm) | |
| Solder Tail Extension | 0.118" (3.000mm) | |
| Attachment Mounting Style | Through Hole | |
| Circuit End Method | Solder | |
| Mating Post Pin Finish | Gold | |
| Mating Post Coating Thickness | - | |
| Visual Hue | Black |
Description
Offered in a shade referred to as Black to enhance the system's aesthetics. Displays the finish of the mating post assessed at Gold. Overall pin length 1.436" (36.480mm) to guarantee precise insertion. Post length 0.118" (3.000mm) for dependable connectivity. Height of the stack 1.200" (30.480mm) for ideal component stacking. Tail length 0.118" (3.000mm) to ensure mechanical clearance. Mounting configuration Through Hole for structural stability. Overall number of positions 32 for switches or mechanical components. Overall rows 1 for setting up matrices or displays. Type of housing Bag for safeguarding or transporting components. Distance 0.100" (2.54mm) for arranging components or aligning connectors. Product status Active concerning availability and lifecycle. Classification series for the product or component WR-PHD. Termination method Solder for electrical or mechanical connections.
