Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | REDCUBE WP-PLUG | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| End Terminal Category | PC Pin | |
| Connection Terminal Design | Wire | |
| Flange-Above Pin Gauge | - | |
| Flange-Below Pin Gauge | - | |
| Flange-Above Extension | 0.433" (11.00mm) | |
| Flange-Below Extension | 0.732" (18.60mm) | |
| Full Overall Length | 1.165" (29.60mm) | |
| Mount Flange Width | 0.355" (9.02mm) | |
| Fixing Hole Size | - | |
| Attachment Mounting Style | Free Hanging (In-Line) | |
| Circuit End Method | Crimp | |
| Protective Insulation Layer | Non-Insulated | |
| Circuit Board Depth | - | |
| Pin Alloy Composition | Copper Alloy | |
| Pin Surface Treatment | Tin | |
| Pin Coating Depth | - |
Description
Includes contact finish plated at Tin to improve conductivity. Constructed from the contact material known as Copper Alloy. Features a flange width noted at 0.355" (9.02mm). Insulation with a rating of Non-Insulated for safety and efficiency. Length above the flange 0.433" (11.00mm) for proper alignment. The length of the extension below the flange 0.732" (18.60mm) for installation purposes. The complete length 1.165" (29.60mm) for thorough dimensional reference. Mounting configuration Free Hanging (In-Line) for structural stability. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Classification series for the product or component REDCUBE WP-PLUG. Design of terminal Wire for connectors or cabling. Classification of terminal PC Pin for electrical or mechanical connections. Termination method Crimp for electrical or mechanical connections.
