Stock:
Distributor: 121
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 6,225.41000 | ₹ 6,225.41 |
| 2 | ₹ 5,577.42000 | ₹ 11,154.84 |
| 3 | ₹ 4,867.48000 | ₹ 14,602.44 |
| 5 | ₹ 4,539.30000 | ₹ 22,696.50 |
| 10 | ₹ 4,409.26000 | ₹ 44,092.60 |
| 20 | ₹ 4,294.21000 | ₹ 85,884.20 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 36DX | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Storage Capacity Electrical | 4800 µF | |
| Accuracy Tolerance Percentage | -10%, +75% | |
| Rated Operating Voltage | 50 V | |
| Series Resistance Equivalent | - | |
| Expected Life at Temperature | 1000 Hrs @ 85°C | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Optical Polarization Mode | Polar | |
| Performance Rating Specs | - | |
| Intended Uses | General Purpose | |
| Low-Freq Ripple Amps | - | |
| High-Freq Ripple Amps | - | |
| AC Resistance Value | - | |
| Pin Lead Gap | 0.500" (12.70mm) | |
| Package Size Specs | 1.453" Dia (36.90mm) | |
| Maximum Mounted Height | 3.252" (82.60mm) | |
| SMD Pad Footprint | - | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | Radial, Can - Screw Terminals |
Description
Perfectly designed for situations involving General Purpose. Provides a capacitance level rated at 4800 µF to maintain circuit stability. Maximum installed height of 3.252" (82.60mm) for components affixed to the board. Lead spacing 0.500" (12.70mm) to meet PCB design requirements. Operates with a durability of 1000 Hrs @ 85°C at specified temperature. Mounting configuration Chassis Mount for structural stability. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case Radial, Can - Screw Terminals that offers mechanical and thermal protection. The Polar type of polarization for optical or RF applications. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component 36DX. Details on package size 1.453" Dia (36.90mm) for electrical or mechanical components. Measurement dimensions 1.453" Dia (36.90mm) for component specifications. Precision tolerance level -10%, +75% in manufacturing processes. The operating voltage rating of the device 50 V.
