Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 28000 | ₹ 30.41000 | ₹ 8,51,480.00 |
| 20000 | ₹ 30.82000 | ₹ 6,16,400.00 |
| 12000 | ₹ 31.51000 | ₹ 3,78,120.00 |
| 8000 | ₹ 32.15000 | ₹ 2,57,200.00 |
| 4000 | ₹ 33.40000 | ₹ 1,33,600.00 |
| 1000 | ₹ 36.77000 | ₹ 36,770.00 |
| 500 | ₹ 39.02000 | ₹ 19,510.00 |
| 100 | ₹ 46.29000 | ₹ 4,629.00 |
| 50 | ₹ 50.59000 | ₹ 2,529.50 |
| 10 | ₹ 64.52000 | ₹ 645.20 |
| 1 | ₹ 99.68000 | ₹ 99.68 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | HighQ MLC-S | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Active | |
| Storage Capacity Electrical | 0.2 pF | |
| Accuracy Tolerance Percentage | ±0.05pF | |
| Rated Operating Voltage | 250V | |
| Temp Drift Factor | C0G, NP0 | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Key Product Highlights | High Q, Low Loss | |
| Performance Rating Specs | AEC-Q200 | |
| Intended Uses | RF, Microwave, High Frequency, Automotive | |
| Reliability Failure Metric | - | |
| Attachment Mounting Style | Surface Mount, MLCC | |
| Component Housing Style | 0805 (2012 Metric) | |
| Package Size Specs | 0.080" L x 0.050" W (2.03mm x 1.27mm) | |
| Maximum Mounted Height | - | |
| Maximum Thickness Limit | 0.046" (1.17mm) | |
| Pin Lead Gap | - | |
| Wire Lead Configuration | - |
Description
Perfectly designed for situations involving RF, Microwave, High Frequency, Automotive. Provides a capacitance level rated at 0.2 pF to maintain circuit stability. Equipped with features categorized as High Q, Low Loss. Mounting configuration Surface Mount, MLCC for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 0805 (2012 Metric) that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Criteria AEC-Q200 for electrical, mechanical, or environmental performance. Classification series for the product or component HighQ MLC-S. Details on package size 0.080" L x 0.050" W (2.03mm x 1.27mm) for electrical or mechanical components. Measurement dimensions 0.080" L x 0.050" W (2.03mm x 1.27mm) for component specifications. The temperature drift factor C0G, NP0 that guarantees performance consistency. The highest permissible thickness 0.046" (1.17mm) according to specification standards. Precision tolerance level ±0.05pF in manufacturing processes. The operating voltage rating of the device 250V.
