Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | WCAP-CSRF | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Storage Capacity Electrical | 5.6 pF | |
| Accuracy Tolerance Percentage | ±0.25pF | |
| Rated Operating Voltage | 25V | |
| Temp Drift Factor | C0G, NP0 | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Key Product Highlights | - | |
| Performance Rating Specs | - | |
| Intended Uses | RF, Microwave, High Frequency | |
| Reliability Failure Metric | - | |
| Attachment Mounting Style | Surface Mount, MLCC | |
| Component Housing Style | 0201 (0603 Metric) | |
| Package Size Specs | 0.024" L x 0.012" W (0.60mm x 0.30mm) | |
| Maximum Mounted Height | - | |
| Maximum Thickness Limit | 0.013" (0.33mm) | |
| Pin Lead Gap | - | |
| Wire Lead Configuration | - |
Description
Perfectly designed for situations involving RF, Microwave, High Frequency. Provides a capacitance level rated at 5.6 pF to maintain circuit stability. Mounting configuration Surface Mount, MLCC for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 0201 (0603 Metric) that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Classification series for the product or component WCAP-CSRF. Details on package size 0.024" L x 0.012" W (0.60mm x 0.30mm) for electrical or mechanical components. Measurement dimensions 0.024" L x 0.012" W (0.60mm x 0.30mm) for component specifications. The temperature drift factor C0G, NP0 that guarantees performance consistency. The highest permissible thickness 0.013" (0.33mm) according to specification standards. Precision tolerance level ±0.25pF in manufacturing processes. The operating voltage rating of the device 25V.
