Stock:
Distributor: 69
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 5 | ₹ 1,938.42000 | ₹ 9,692.10 |
| 10 | ₹ 1,615.35000 | ₹ 16,153.50 |
| 120 | ₹ 1,462.27000 | ₹ 1,75,472.40 |
| 520 | ₹ 1,427.56000 | ₹ 7,42,331.20 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | PrizmaCap™ SCP | |
| IC Encapsulation Type | Tray | |
| Availability Status | Active | |
| Storage Capacity Electrical | 6 F | |
| Accuracy Tolerance Percentage | -10%, +30% | |
| Rated Operating Voltage | 2.5 V | |
| Series Resistance Equivalent | 230mOhm @ 1kHz | |
| Expected Life at Temperature | 2000 Hrs @ 65°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Circuit End Method | SMD (SMT) Tabs | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | Nonstandard SMD | |
| Pin Lead Gap | - | |
| Package Size Specs | 1.969" L x 1.811" W (50.00mm x 46.00mm) | |
| Maximum Mounted Height | 0.091" (2.30mm) | |
| Ambient Temp Range | -25°C ~ 65°C |
Description
Provides a capacitance level rated at 6 F to maintain circuit stability. Displays ESR rated at 230mOhm @ 1kHz. Maximum installed height of 0.091" (2.30mm) for components affixed to the board. Operates with a durability of 2000 Hrs @ 65°C at specified temperature. Mounting configuration Surface Mount for structural stability. Temperature range -25°C ~ 65°C for environmental conditions impacting thermal efficiency. Type of housing Tray for safeguarding or transporting components. Style of the enclosure/case Nonstandard SMD that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Classification series for the product or component PrizmaCap™ SCP. Details on package size 1.969" L x 1.811" W (50.00mm x 46.00mm) for electrical or mechanical components. Measurement dimensions 1.969" L x 1.811" W (50.00mm x 46.00mm) for component specifications. Termination method SMD (SMT) Tabs for electrical or mechanical connections. Precision tolerance level -10%, +30% in manufacturing processes. The operating voltage rating of the device 2.5 V.
