Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | RG | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Storage Capacity Electrical | 220 mF | |
| Accuracy Tolerance Percentage | -20%, +80% | |
| Rated Operating Voltage | 3.6 V | |
| Series Resistance Equivalent | 50Ohm @ 1kHz | |
| Expected Life at Temperature | 2000 Hrs @ 85°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Circuit End Method | PC Pins | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | Axial, Can - Vertical | |
| Pin Lead Gap | 0.197" (5.00mm) | |
| Package Size Specs | 0.413" Dia x 0.197" W (10.50mm x 5.00mm) | |
| Maximum Mounted Height | 0.453" (11.50mm) | |
| Ambient Temp Range | -25°C ~ 85°C |
Description
Provides a capacitance level rated at 220 mF to maintain circuit stability. Displays ESR rated at 50Ohm @ 1kHz. Maximum installed height of 0.453" (11.50mm) for components affixed to the board. Lead spacing 0.197" (5.00mm) to meet PCB design requirements. Operates with a durability of 2000 Hrs @ 85°C at specified temperature. Mounting configuration Through Hole for structural stability. Temperature range -25°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case Axial, Can - Vertical that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component RG. Details on package size 0.413" Dia x 0.197" W (10.50mm x 5.00mm) for electrical or mechanical components. Measurement dimensions 0.413" Dia x 0.197" W (10.50mm x 5.00mm) for component specifications. Termination method PC Pins for electrical or mechanical connections. Precision tolerance level -20%, +80% in manufacturing processes. The operating voltage rating of the device 3.6 V.
