Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 45 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Device Type Classification | Flexible Heater, Foil | |
| Heat Tolerance Grade | 365°F (185°C) | |
| Power Density at 12V | 10 W/in² | |
| Wattage Power Level | 400 W | |
| Electrical Voltage Rating | - | |
| Ohm Resistance Value | 0.4 Ohms | |
| Physical Shape Form | Rectangular | |
| Linear Length Dimension | 10.000" (254.00mm) | |
| Horizontal Width Dimension | 4.000" (101.60mm) | |
| Circular Measurement | - | |
| Material Thickness Gauge | - | |
| Construction Material Type | Polyimide | |
| Mounting Technique | Pressure Sensitive Adhesive (PSA) | |
| Circuit End Method | Wire Leads | |
| Lead Wire Extension | 12.000" (304.80mm) | |
| Dielectric Barrier Type | Polytetrafluoroethylene (PTFE) | |
| AWG Wire Size | 18 AWG | |
| Visual Hue | Amber | |
| Certification Body | - | |
| Key Product Highlights | Leads Potted, User Selectable Voltage |
Description
Fastened using a Pressure Sensitive Adhesive (PSA) method for dependable placement. Offered in a shade referred to as Amber to enhance the system's aesthetics. Equipped with features categorized as Leads Potted, User Selectable Voltage. Overall length 10.000" (254.00mm) for size indication. The length of the lead wire 12.000" (304.80mm) for reliable connectivity. Type of construction material Polyimide for durability and efficiency. Substance Polytetrafluoroethylene (PTFE) to guarantee electrical safety via insulation. Type of housing Bulk for safeguarding or transporting components. Power measured in watts 400 W for optimal operation. Product status Active concerning availability and lifecycle. Resistance value 0.4 Ohms for electrical performance. Classification series for the product or component 45. Shape Rectangular for the part or device. Temperature standard 365°F (185°C) for device reliability. Termination method Wire Leads for electrical or mechanical connections. Type classification Flexible Heater, Foil for specifications. Density of power at 12V 10 W/in² for electronic devices. Horizontal width measurement 4.000" (101.60mm). Size of wire gauge 18 AWG according to electrical standards.
