Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 52 | ₹ 511.75000 | ₹ 26,611.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | Tariff may apply if shipping to the United States | |
| Product Series Line | LM35-20Bxx (35W) | |
| IC Encapsulation Type | Box | |
| Availability Status | Not For New Designs | |
| Device Type Classification | Enclosed | |
| Signal Output Quantity | 1 | |
| Supply Input Volts | 85 ~ 264 VAC, 120 ~ 373 VDC | |
| First Rail Output Volts | 15V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Fifth Rail Output Volts | - | |
| Sixth Rail Output Volts | - | |
| First Output Current | 2.4 A | |
| Second Output Current | - | |
| Third Output Current | - | |
| Fourth Output Current | - | |
| Fifth Output Current | - | |
| Sixth Output Current | - | |
| Wattage Power Level | 36W | |
| Intended Uses | Household Appliances, ITE (Commercial) | |
| Isolation Barrier Voltage | 4 kV | |
| Performance Efficiency Rating | 89% | |
| Ambient Temp Range | -30°C ~ 70°C (With Derating) | |
| Key Product Highlights | Adjustable Output, Standby Output, Universal Input | |
| Attachment Mounting Style | Chassis Mount | |
| Package Size Specs | 3.90" L x 3.23" W x 1.18" H (99.0mm x 82.0mm x 30.0mm) | |
| Certification Body | CB, CCC, CE, cURus | |
| Compliance Standard ID | 60335-1; 62368-1 |
Description
Perfectly designed for situations involving Household Appliances, ITE (Commercial). Complies with the criteria of entities acknowledged as CB, CCC, CE, cURus. Assesses resistance at forward current Tariff may apply if shipping to the United States for LED or diode testing. Represents the current for output 1 set to 2.4 A. Offers an efficiency rating calculated at 89%. Equipped with features categorized as Adjustable Output, Standby Output, Universal Input. The input voltage established at 85 ~ 264 VAC, 120 ~ 373 VDC for reliable performance. Mounting configuration Chassis Mount for structural stability. Overall outputs 1 for device connections. Temperature range -30°C ~ 70°C (With Derating) for environmental conditions impacting thermal efficiency. Voltage 15V for optimal output electric potential. Type of housing Box for safeguarding or transporting components. Power measured in watts 36W for optimal operation. Product status Not For New Designs concerning availability and lifecycle. Classification series for the product or component LM35-20Bxx (35W). Details on package size 3.90" L x 3.23" W x 1.18" H (99.0mm x 82.0mm x 30.0mm) for electrical or mechanical components. Measurement dimensions 3.90" L x 3.23" W x 1.18" H (99.0mm x 82.0mm x 30.0mm) for component specifications. Standard compliance code 60335-1; 62368-1 for regulations. Current supply level 85 ~ 264 VAC, 120 ~ 373 VDC for electrical parameters. The classification for import duties Tariff may apply if shipping to the United States related to import and export transactions. Type classification Enclosed for specifications. Maximum Vce(on) at Vge Tariff may apply if shipping to the United States for transistor specifications. Input voltage 85 ~ 264 VAC, 120 ~ 373 VDC required for devices. Isolation voltage 4 kV for electrical safety. Output 1 voltage 15V across different outputs.
