Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | S8E3 (30W) | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Device Type Classification | Enclosed | |
| Signal Output Quantity | 3 | |
| Supply Input Volts | 85 ~ 132 VAC | |
| First Rail Output Volts | 5V | |
| Second Rail Output Volts | 12V | |
| Third Rail Output Volts | -12V | |
| Fourth Rail Output Volts | - | |
| Fifth Rail Output Volts | - | |
| Sixth Rail Output Volts | - | |
| First Output Current | 3 A | |
| Second Output Current | 1.2 A | |
| Third Output Current | 300 mA | |
| Fourth Output Current | - | |
| Fifth Output Current | - | |
| Sixth Output Current | - | |
| Wattage Power Level | 30W | |
| Intended Uses | ITE (Commercial) | |
| Isolation Barrier Voltage | 2 kV | |
| Performance Efficiency Rating | 73% | |
| Ambient Temp Range | -10°C ~ 70°C (With Derating) | |
| Key Product Highlights | Adjustable Output | |
| Attachment Mounting Style | Chassis Mount | |
| Package Size Specs | 6.77" L x 2.71" W x 1.30" H (172.0mm x 69.0mm x 33.0mm) | |
| Certification Body | CSA, UR | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving ITE (Commercial). Complies with the criteria of entities acknowledged as CSA, UR. Represents the current for output 1 set to 3 A. Records the current for output 2 at 1.2 A. Indicates the current for output 3 at 300 mA. Offers an efficiency rating calculated at 73%. Equipped with features categorized as Adjustable Output. The input voltage established at 85 ~ 132 VAC for reliable performance. Mounting configuration Chassis Mount for structural stability. Overall outputs 3 for device connections. Temperature range -10°C ~ 70°C (With Derating) for environmental conditions impacting thermal efficiency. Voltage 5V for optimal output electric potential. Type of housing Bulk for safeguarding or transporting components. Power measured in watts 30W for optimal operation. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component S8E3 (30W). Details on package size 6.77" L x 2.71" W x 1.30" H (172.0mm x 69.0mm x 33.0mm) for electrical or mechanical components. Measurement dimensions 6.77" L x 2.71" W x 1.30" H (172.0mm x 69.0mm x 33.0mm) for component specifications. Current supply level 85 ~ 132 VAC for electrical parameters. Type classification Enclosed for specifications. Input voltage 85 ~ 132 VAC required for devices. Isolation voltage 2 kV for electrical safety. Output 1 voltage 5V across different outputs. Output 2 voltage 12V across different outputs. Output 3 voltage -12V across different outputs.
