Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | OptiMOS™ | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Active | |
| Device Type Classification | Non-Isolated PoL Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 4.25V | |
| Maximum Input Voltage | 16V | |
| First Rail Output Volts | 0.225 ~ 3V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 160A | |
| Wattage Power Level | 480 W | |
| Isolation Barrier Voltage | - | |
| Intended Uses | ITE (Commercial) | |
| Key Product Highlights | Adjustable Output, Remote On/Off | |
| Ambient Temp Range | -40°C ~ 125°C | |
| Performance Efficiency Rating | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 72-LGA Module | |
| Package Size Specs | 0.39" L x 0.35" W x 0.31" H (10.0mm x 9.0mm x 8.0mm) | |
| Vendor Package Type | LG-MLGA-72-6 | |
| Adjustment Capabilities | Enable, Active High | |
| Certification Body | - | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving ITE (Commercial). Is equipped with control features recognized as Enable, Active High. Supplies peak output current defined as 160A. Equipped with features categorized as Adjustable Output, Remote On/Off. The input voltage established at 4.25V for reliable performance. Mounting configuration Surface Mount for structural stability. Overall outputs 1 for device connections. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Voltage 0.225 ~ 3V for optimal output electric potential. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 72-LGA Module that offers mechanical and thermal protection. Type of package LG-MLGA-72-6 that preserves the integrity of the device. Power measured in watts 480 W for optimal operation. Product status Active concerning availability and lifecycle. Classification series for the product or component OptiMOS™. Details on package size 0.39" L x 0.35" W x 0.31" H (10.0mm x 9.0mm x 8.0mm) for electrical or mechanical components. Measurement dimensions 0.39" L x 0.35" W x 0.31" H (10.0mm x 9.0mm x 8.0mm) for component specifications. Supplier package type LG-MLGA-72-6 for component selection. Type classification Non-Isolated PoL Module for specifications. Maximum input voltage 16V for safeguarding. Minimum input voltage 4.25V for operation. Output 1 voltage 0.225 ~ 3V across different outputs.
