Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | U3V50 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Device Type Classification | Non-Isolated PoL Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 2.9V | |
| Maximum Input Voltage | 12V | |
| First Rail Output Volts | 4 ~ 12V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 3A | |
| Wattage Power Level | 48 W | |
| Isolation Barrier Voltage | - | |
| Intended Uses | - | |
| Key Product Highlights | Adjustable Output | |
| Ambient Temp Range | - | |
| Performance Efficiency Rating | 95% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 8-DIP Module | |
| Package Size Specs | 1.90" L x 0.60" W x 0.41" H (48.3mm x 15.2mm x 10.4mm) | |
| Vendor Package Type | - | |
| Adjustment Capabilities | Enable, Active Floating | |
| Certification Body | - | |
| Compliance Standard ID | - |
Description
Is equipped with control features recognized as Enable, Active Floating. Supplies peak output current defined as 3A. Offers an efficiency rating calculated at 95%. Equipped with features categorized as Adjustable Output. The input voltage established at 2.9V for reliable performance. Mounting configuration Through Hole for structural stability. Overall outputs 1 for device connections. Voltage 4 ~ 12V for optimal output electric potential. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case 8-DIP Module that offers mechanical and thermal protection. Power measured in watts 48 W for optimal operation. Product status Active concerning availability and lifecycle. Classification series for the product or component U3V50. Details on package size 1.90" L x 0.60" W x 0.41" H (48.3mm x 15.2mm x 10.4mm) for electrical or mechanical components. Measurement dimensions 1.90" L x 0.60" W x 0.41" H (48.3mm x 15.2mm x 10.4mm) for component specifications. Type classification Non-Isolated PoL Module for specifications. Maximum input voltage 12V for safeguarding. Minimum input voltage 2.9V for operation. Output 1 voltage 4 ~ 12V across different outputs.
