Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tube | |
| Availability Status | Obsolete | |
| Device Type Classification | Non-Isolated PoL Module | |
| Signal Output Quantity | 2 | |
| Minimum Input Voltage | 4.5V | |
| Maximum Input Voltage | 20V | |
| First Rail Output Volts | 0.6 ~ 2.5V | |
| Second Rail Output Volts | 0.6 ~ 2.5V | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 20A, 20A | |
| Wattage Power Level | - | |
| Isolation Barrier Voltage | - | |
| Intended Uses | ITE (Commercial) | |
| Key Product Highlights | OCP, OTP, OVP | |
| Ambient Temp Range | -40°C ~ 125°C | |
| Performance Efficiency Rating | 94% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 26-PowerBQFN Module | |
| Package Size Specs | 0.67" L x 0.67" W x 0.30" H (17.0mm x 17.0mm x 7.5mm) | |
| Vendor Package Type | 26-QFN (17x17) | |
| Adjustment Capabilities | - | |
| Certification Body | - | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving ITE (Commercial). Supplies peak output current defined as 20A, 20A. Offers an efficiency rating calculated at 94%. Equipped with features categorized as OCP, OTP, OVP. The input voltage established at 4.5V for reliable performance. Mounting configuration Surface Mount for structural stability. Overall outputs 2 for device connections. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Voltage 0.6 ~ 2.5V for optimal output electric potential. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case 26-PowerBQFN Module that offers mechanical and thermal protection. Type of package 26-QFN (17x17) that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Details on package size 0.67" L x 0.67" W x 0.30" H (17.0mm x 17.0mm x 7.5mm) for electrical or mechanical components. Measurement dimensions 0.67" L x 0.67" W x 0.30" H (17.0mm x 17.0mm x 7.5mm) for component specifications. Supplier package type 26-QFN (17x17) for component selection. Type classification Non-Isolated PoL Module for specifications. Maximum input voltage 20V for safeguarding. Minimum input voltage 4.5V for operation. Output 1 voltage 0.6 ~ 2.5V across different outputs. Output 2 voltage 0.6 ~ 2.5V across different outputs.
