Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tray | |
| Availability Status | Active | |
| Internal Structure Design | Single | |
| Thyristor Diode Count | 1 SCR | |
| Off-State Voltage Rating | 1.8 kV | |
| Max Average On-State Current | 2610 A | |
| Max RMS On-State Current | 4100 A | |
| Max Gate Trigger Volts | 2 V | |
| Max Gate Trigger Amps | 250 mA | |
| Non-Repetitive Surge 50/60Hz | 44000A @ 50Hz | |
| Maximum Holding Current | 300 mA | |
| Ambient Temp Range | 135°C (TJ) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | TO-200AD |
Description
Features a maximum gate trigger current (Igt) rated at 250 mA. Indicates the maximum holding current recorded at 300 mA. Is designed to manage surge current Itsm rated at 44000A @ 50Hz for 50/60Hz. Offers a maximum average on-state current It(AV) of 2610 A. Supports RMS on-state current rated at 4100 A. Mounting configuration Chassis Mount for structural stability. Overall count of SCRs/diodes 1 SCR for circuit safeguarding. Temperature range 135°C (TJ) for environmental conditions impacting thermal efficiency. Type of housing Tray for safeguarding or transporting components. Style of the enclosure/case TO-200AD that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Configuration Single for components or materials. Maximum gate trigger voltage 2 V for SCR devices. The voltage 1.8 kV when the device is not active for switches or semiconductors.
