Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Internal Structure Design | Series Connection - All SCRs | |
| Thyristor Diode Count | 2 SCRs | |
| Off-State Voltage Rating | 2.2 kV | |
| Max Average On-State Current | 104 A | |
| Max RMS On-State Current | 160 A | |
| Max Gate Trigger Volts | 1.4 V | |
| Max Gate Trigger Amps | 200 mA | |
| Non-Repetitive Surge 50/60Hz | 1050A @ 50Hz | |
| Maximum Holding Current | 200 mA | |
| Ambient Temp Range | -40°C ~ 140°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | Module |
Description
Features a maximum gate trigger current (Igt) rated at 200 mA. Indicates the maximum holding current recorded at 200 mA. Is designed to manage surge current Itsm rated at 1050A @ 50Hz for 50/60Hz. Offers a maximum average on-state current It(AV) of 104 A. Supports RMS on-state current rated at 160 A. Mounting configuration Chassis Mount for structural stability. Overall count of SCRs/diodes 2 SCRs for circuit safeguarding. Temperature range -40°C ~ 140°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case Module that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Configuration Series Connection - All SCRs for components or materials. Maximum gate trigger voltage 1.4 V for SCR devices. The voltage 2.2 kV when the device is not active for switches or semiconductors.
