Stock:
Distributor: 116
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 384 | ₹ 17,800.00000 | ₹ 68,35,200.00 |
| 192 | ₹ 18,165.55000 | ₹ 34,87,785.60 |
| 96 | ₹ 18,599.07000 | ₹ 17,85,510.72 |
| 48 | ₹ 19,031.15000 | ₹ 9,13,495.20 |
| 24 | ₹ 19,483.78000 | ₹ 4,67,610.72 |
Stock:
Distributor: 11
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 12 | ₹ 20,290.22000 | ₹ 2,43,482.64 |
| 6 | ₹ 20,689.83000 | ₹ 1,24,138.98 |
| 3 | ₹ 22,599.77000 | ₹ 67,799.31 |
| 1 | ₹ 24,377.99000 | ₹ 24,377.99 |
Stock:
Distributor: 121
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 42,917.08000 | ₹ 42,917.08 |
| 5 | ₹ 39,128.47000 | ₹ 1,95,642.35 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Internal Structure Design | Bridge, 3-Phase - SCRs/Diodes | |
| Thyristor Diode Count | 1 SCR, 6 Diodes | |
| Off-State Voltage Rating | 1.6 kV | |
| Max Average On-State Current | 200 A | |
| Max RMS On-State Current | - | |
| Max Gate Trigger Volts | 3 V | |
| Max Gate Trigger Amps | 150 mA | |
| Non-Repetitive Surge 50/60Hz | 4000A @ 50Hz | |
| Maximum Holding Current | 100 mA | |
| Ambient Temp Range | -40°C ~ 150°C (TJ) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | Module |
Description
Features a maximum gate trigger current (Igt) rated at 150 mA. Indicates the maximum holding current recorded at 100 mA. Is designed to manage surge current Itsm rated at 4000A @ 50Hz for 50/60Hz. Offers a maximum average on-state current It(AV) of 200 A. Mounting configuration Chassis Mount for structural stability. Overall count of SCRs/diodes 1 SCR, 6 Diodes for circuit safeguarding. Temperature range -40°C ~ 150°C (TJ) for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case Module that offers mechanical and thermal protection. Configuration Bridge, 3-Phase - SCRs/Diodes for components or materials. Maximum gate trigger voltage 3 V for SCR devices. The voltage 1.6 kV when the device is not active for switches or semiconductors.
