Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 500 | ₹ 1,046.89000 | ₹ 5,23,445.00 |
| 250 | ₹ 1,084.18000 | ₹ 2,71,045.00 |
| 100 | ₹ 1,135.48000 | ₹ 1,13,548.00 |
| 50 | ₹ 1,175.87000 | ₹ 58,793.50 |
| 25 | ₹ 1,217.65000 | ₹ 30,441.25 |
| 10 | ₹ 1,275.15000 | ₹ 12,751.50 |
| 1 | ₹ 1,431.37000 | ₹ 1,431.37 |
Stock:
Distributor: 113
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 5 | ₹ 1,856.54000 | ₹ 9,282.70 |
| 25 | ₹ 1,650.95000 | ₹ 41,273.75 |
| 50 | ₹ 1,583.67000 | ₹ 79,183.50 |
| 100 | ₹ 1,547.53000 | ₹ 1,54,753.00 |
| 250 | ₹ 1,477.76000 | ₹ 3,69,440.00 |
| 500 | ₹ 1,414.21000 | ₹ 7,07,105.00 |
| 1000 | ₹ 1,406.73000 | ₹ 14,06,730.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | RH | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Chassis Mount | |
| Inductor Operating Volts | 240VAC | |
| Switch Contact Layout | DPDT (2 Form C) | |
| Pin Ampere Capacity | 10 A | |
| Switch Rated Volts | 240VAC, 30VDC - Max | |
| Maximum Switch Load | 2400VA, 300W | |
| Electromagnet Amp Draw | 4.6 mA | |
| Electromagnetic Coil Design | Non Latching | |
| Key Product Highlights | - | |
| Lead Termination Type | Quick Connect - 0.187" (4.7mm) | |
| Sealing Protection Grade | - | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | 192 VAC | |
| Release Voltage Level | 72 VAC | |
| Activation Response Time | 20 ms | |
| Reset Response Duration | 20 ms | |
| Ambient Temp Range | -25°C ~ 70°C | |
| Pin Alloy Composition | Silver Cadmium Oxide (AgCdO) | |
| Certification Body | CE, CSA, cURus, TUV | |
| Electromechanical Relay Style | General Purpose | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
