Stock:
Distributor: 114
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 1,658.96000 | ₹ 1,658.96 |
| 10 | ₹ 1,472.06000 | ₹ 14,720.60 |
| 25 | ₹ 1,407.09000 | ₹ 35,177.25 |
| 51 | ₹ 1,367.04000 | ₹ 69,719.04 |
| 106 | ₹ 1,274.48000 | ₹ 1,35,094.88 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | RH | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Socketable | |
| Inductor Operating Volts | 240VAC | |
| Switch Contact Layout | 4PDT (4 Form C) | |
| Pin Ampere Capacity | 10 A | |
| Switch Rated Volts | 240VAC, 30VDC - Max | |
| Maximum Switch Load | 2400VA, 300W | |
| Electromagnet Amp Draw | 8.3 mA | |
| Electromagnetic Coil Design | Non Latching | |
| Key Product Highlights | - | |
| Lead Termination Type | Plug In, Quick Connect - 0.187" (4.7mm) | |
| Sealing Protection Grade | - | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | 192 VAC | |
| Release Voltage Level | 72 VAC | |
| Activation Response Time | 25 ms | |
| Reset Response Duration | 25 ms | |
| Ambient Temp Range | -25°C ~ 70°C | |
| Pin Alloy Composition | Silver Cadmium Oxide (AgCdO) | |
| Certification Body | CE, CSA, cURus, TUV | |
| Electromechanical Relay Style | General Purpose | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
