Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | G7J | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Chassis Mount | |
| Inductor Operating Volts | 24VDC | |
| Switch Contact Layout | 4PST-NO (DM) (4 Form X) | |
| Pin Ampere Capacity | 25 A | |
| Switch Rated Volts | 250VAC, 125VDC - Max | |
| Maximum Switch Load | 6250VA, 3125W | |
| Electromagnet Amp Draw | 83 mA | |
| Electromagnetic Coil Design | Non Latching | |
| Key Product Highlights | Test Button | |
| Lead Termination Type | Screw Terminal | |
| Sealing Protection Grade | - | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | 18 VDC | |
| Release Voltage Level | 2.4 VDC | |
| Activation Response Time | 50 ms | |
| Reset Response Duration | 50 ms | |
| Ambient Temp Range | -25°C ~ 60°C | |
| Pin Alloy Composition | - | |
| Certification Body | CE, CSA, UR | |
| Electromechanical Relay Style | General Purpose | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Complies with the criteria of entities acknowledged as CE, CSA, UR. Supports coil current measured at 83 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 24VDC for reliable functionality. Utilizes a contact configuration categorized as 4PST-NO (DM) (4 Form X). Supports a contact current rating of 25 A. Equipped with features categorized as Test Button. The maximum switching load 6250VA, 3125W for enhanced circuit performance. Mounting configuration Chassis Mount for structural stability. Needs a voltage of 18 VDC for effective activation. Requires a release voltage of 2.4 VDC for reliable functioning. Time duration 50 ms for the response upon activation. Temperature range -25°C ~ 60°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Configuration of relay General Purpose for controlling electrical circuits. Duration required 50 ms for reset and reaction. Classification series for the product or component G7J. The switch's voltage specification 250VAC, 125VDC - Max as per electrical regulations. Type of termination Screw Terminal for connector or device.
