Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | RIF | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | DIN Rail | |
| Inductor Operating Volts | 24VAC | |
| Switch Contact Layout | 4PDT (4 Form C) | |
| Pin Ampere Capacity | 5 A | |
| Switch Rated Volts | 250VAC, 250VDC - Max | |
| Maximum Switch Load | - | |
| Electromagnet Amp Draw | 70 mA | |
| Electromagnetic Coil Design | Non Latching | |
| Key Product Highlights | Lighted Indicator, Socket Included, Varistor | |
| Lead Termination Type | Spring Terminal | |
| Sealing Protection Grade | - | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | - | |
| Release Voltage Level | - | |
| Activation Response Time | 15 ms | |
| Reset Response Duration | 20 ms | |
| Ambient Temp Range | -40°C ~ 50°C | |
| Pin Alloy Composition | Silver Nickel (AgNi) | |
| Certification Body | CSA | |
| Electromechanical Relay Style | General Purpose | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Complies with the criteria of entities acknowledged as CSA. Supports coil current measured at 70 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 24VAC for reliable functionality. Utilizes a contact configuration categorized as 4PDT (4 Form C). Constructed from the contact material known as Silver Nickel (AgNi). Supports a contact current rating of 5 A. Equipped with features categorized as Lighted Indicator, Socket Included, Varistor. Mounting configuration DIN Rail for structural stability. Time duration 15 ms for the response upon activation. Temperature range -40°C ~ 50°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Configuration of relay General Purpose for controlling electrical circuits. Duration required 20 ms for reset and reaction. Classification series for the product or component RIF. The switch's voltage specification 250VAC, 250VDC - Max as per electrical regulations. Type of termination Spring Terminal for connector or device.
