Stock:
Distributor: 118
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 74 | ₹ 1,160.34000 | ₹ 85,865.16 |
| 18 | ₹ 1,226.64000 | ₹ 22,079.52 |
| 1 | ₹ 1,491.86000 | ₹ 1,491.86 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | RK | |
| IC Encapsulation Type | Tube | |
| Availability Status | Obsolete | |
| Electromagnetic Coil Design | Latching, Dual Coil | |
| Electromagnet Amp Draw | 33.3 mA | |
| Inductor Operating Volts | 12VDC | |
| Switch Contact Layout | SPDT (1 Form C) | |
| Pin Ampere Capacity | 10 mA | |
| Switch Rated Volts | 30VDC - Max | |
| Minimum Activation Volts | 9 VDC | |
| Release Voltage Level | - | |
| Activation Response Time | 10 ms | |
| Reset Response Duration | 6 ms | |
| Key Product Highlights | Sealed - Fully | |
| Attachment Mounting Style | Through Hole | |
| Lead Termination Type | PC Pin | |
| Ambient Temp Range | -40°C ~ 70°C |
Description
Supports coil current measured at 33.3 mA. Designed with a coil type classified as Latching, Dual Coil for optimal electrical efficiency. Operates with a coil voltage of 12VDC for reliable functionality. Utilizes a contact configuration categorized as SPDT (1 Form C). Supports a contact current rating of 10 mA. Equipped with features categorized as Sealed - Fully. Mounting configuration Through Hole for structural stability. Needs a voltage of 9 VDC for effective activation. Time duration 10 ms for the response upon activation. Temperature range -40°C ~ 70°C for environmental conditions impacting thermal efficiency. Type of housing Tube for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Duration required 6 ms for reset and reaction. Classification series for the product or component RK. The switch's voltage specification 30VDC - Max as per electrical regulations. Type of termination PC Pin for connector or device.
