Stock:
Distributor: 11
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 3 | ₹ 3,639.21000 | ₹ 10,917.63 |
| 1 | ₹ 3,918.67000 | ₹ 3,918.67 |
Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 12 | ₹ 7,920.11000 | ₹ 95,041.32 |
| 60 | ₹ 7,156.49000 | ₹ 4,29,389.40 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | HF | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Electromagnetic Coil Design | Non Latching | |
| Electromagnet Amp Draw | 47.9 mA | |
| Inductor Operating Volts | 12VDC | |
| Switch Contact Layout | SPST-NO (1 Form A) | |
| Pin Ampere Capacity | 1.5 A | |
| Switch Rated Volts | 500VAC, 500VDC - Max | |
| Minimum Activation Volts | 8.4 VDC | |
| Release Voltage Level | 1.8 VDC | |
| Activation Response Time | 3 ms | |
| Reset Response Duration | 1 ms | |
| Key Product Highlights | - | |
| Attachment Mounting Style | Through Hole | |
| Lead Termination Type | PC Pin | |
| Ambient Temp Range | -40°C ~ 85°C |
Description
Supports coil current measured at 47.9 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 12VDC for reliable functionality. Utilizes a contact configuration categorized as SPST-NO (1 Form A). Supports a contact current rating of 1.5 A. Mounting configuration Through Hole for structural stability. Needs a voltage of 8.4 VDC for effective activation. Requires a release voltage of 1.8 VDC for reliable functioning. Time duration 3 ms for the response upon activation. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Duration required 1 ms for reset and reaction. Classification series for the product or component HF. The switch's voltage specification 500VAC, 500VDC - Max as per electrical regulations. Type of termination PC Pin for connector or device.
