Description

Complies with the criteria of entities acknowledged as BSI, cURus. Supports coil current measured at 11.7 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 12VDC for reliable functionality. Utilizes a contact configuration categorized as DPDT (2 Form C). Constructed from the contact material known as Silver (Ag), Gold (Au). Supports a contact current rating of 2 A. The maximum switching load 500VA, 440W for enhanced circuit performance. Mounting configuration Surface Mount for structural stability. Needs a voltage of 9 VDC for effective activation. Requires a release voltage of 1.2 VDC for reliable functioning. Time duration 4 ms for the response upon activation. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tube for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Configuration of relay General Purpose for controlling electrical circuits. Duration required 4 ms for reset and reaction. Ingress protection level Sealed - Fully for sealing. Classification series for the product or component TX-TH. The switch's voltage specification 250VAC, 220VDC - Max as per electrical regulations. Type of termination Gull Wing for connector or device.
