Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | FP2, AXICOM | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Attachment Mounting Style | Through Hole | |
| Inductor Operating Volts | 6VDC | |
| Switch Contact Layout | DPDT (2 Form C) | |
| Pin Ampere Capacity | 2 A | |
| Switch Rated Volts | 250VAC, 220VDC - Max | |
| Maximum Switch Load | 500VA, 440W | |
| Electromagnet Amp Draw | 33.3 mA | |
| Electromagnetic Coil Design | Latching, Dual Coil | |
| Key Product Highlights | - | |
| Lead Termination Type | PC Pin | |
| Sealing Protection Grade | - | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | 4.2 VDC | |
| Release Voltage Level | - | |
| Activation Response Time | 20 ms | |
| Reset Response Duration | 20 ms | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Pin Alloy Composition | Palladium (Pd), Ruthenium (Ru), Gold (Au) | |
| Certification Body | cURus | |
| Electromechanical Relay Style | Telecom | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Complies with the criteria of entities acknowledged as cURus. Supports coil current measured at 33.3 mA. Designed with a coil type classified as Latching, Dual Coil for optimal electrical efficiency. Operates with a coil voltage of 6VDC for reliable functionality. Utilizes a contact configuration categorized as DPDT (2 Form C). Constructed from the contact material known as Palladium (Pd), Ruthenium (Ru), Gold (Au). Supports a contact current rating of 2 A. The maximum switching load 500VA, 440W for enhanced circuit performance. Mounting configuration Through Hole for structural stability. Needs a voltage of 4.2 VDC for effective activation. Time duration 20 ms for the response upon activation. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Configuration of relay Telecom for controlling electrical circuits. Duration required 20 ms for reset and reaction. Classification series for the product or component FP2, AXICOM. The switch's voltage specification 250VAC, 220VDC - Max as per electrical regulations. Type of termination PC Pin for connector or device.
