Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | ChipGuard® MLA | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Active | |
| Peak AC Voltage Rating | 25 V | |
| Peak DC Voltage Limit | 32 V | |
| Min Clamp Voltage | 51.9 V | |
| Typical Varistor Voltage | 61.45 V | |
| Max Clamp Voltage | 71 V | |
| Surge Current Tolerance | 5 A | |
| Stored Energy Capacity | 0.25J | |
| Electrical Circuit Count | 1 | |
| Capacitance at Specific Hz | 12 pF @ 1 kHz | |
| Ambient Temp Range | -55°C ~ 125°C (TA) | |
| Key Product Highlights | - | |
| Quality Grade Level | Automotive | |
| Certification Qualification | AEC-Q200 | |
| Attachment Mounting Style | Surface Mount, MLCV | |
| Component Housing Style | 0603 (1608 Metric) |
Description
Delivers capacitance at a specified frequency of 12 pF @ 1 kHz. Is capable of withstanding surge current levels marked at 5 A. Represents the energy capacity noted at 0.25J. Evaluated as Automotive grade for quality control. Maximum signal delay 71 V at voltage for applications sensitive to timing. Maximum AC voltage 25 V for safe operation. Maximum DC voltage 32 V for safe electronic circuits. Mounting configuration Surface Mount, MLCV for structural stability. The total number of circuits stands at 1 for electrical or electronic setups. Temperature range -55°C ~ 125°C (TA) for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 0603 (1608 Metric) that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Certification AEC-Q200 for compliance with testing or regulatory standards. Classification series for the product or component ChipGuard® MLA. Maximum varistor voltage 71 V for device protection. Minimum varistor voltage 51.9 V for device protection. Standard varistor voltage 61.45 V employed for circuit protection.
