Stock:
Distributor: 69
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 50 | ₹ 14.42000 | ₹ 721.00 |
| 100 | ₹ 14.24000 | ₹ 1,424.00 |
| 250 | ₹ 13.97000 | ₹ 3,492.50 |
| 500 | ₹ 13.79000 | ₹ 6,895.00 |
| 1000 | ₹ 13.53000 | ₹ 13,530.00 |
| 2000 | ₹ 13.17000 | ₹ 26,340.00 |
| 5000 | ₹ 12.90000 | ₹ 64,500.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | ZNR® | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Peak AC Voltage Rating | 150 V | |
| Peak DC Voltage Limit | 200 V | |
| Min Clamp Voltage | 216 V | |
| Typical Varistor Voltage | 240 V | |
| Max Clamp Voltage | 264 V | |
| Surge Current Tolerance | 6 kA | |
| Stored Energy Capacity | 84J | |
| Electrical Circuit Count | 1 | |
| Capacitance at Specific Hz | 700 pF @ 1 kHz | |
| Ambient Temp Range | -40°C ~ 85°C (TA) | |
| Key Product Highlights | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | Disc 15.5mm |
Description
Delivers capacitance at a specified frequency of 700 pF @ 1 kHz. Is capable of withstanding surge current levels marked at 6 kA. Represents the energy capacity noted at 84J. Maximum signal delay 264 V at voltage for applications sensitive to timing. Maximum AC voltage 150 V for safe operation. Maximum DC voltage 200 V for safe electronic circuits. Mounting configuration Through Hole for structural stability. The total number of circuits stands at 1 for electrical or electronic setups. Temperature range -40°C ~ 85°C (TA) for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case Disc 15.5mm that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Classification series for the product or component ZNR®. Maximum varistor voltage 264 V for device protection. Minimum varistor voltage 216 V for device protection. Standard varistor voltage 240 V employed for circuit protection.
