Stock:
Distributor: 121
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 206.45000 | ₹ 206.45 |
| 5 | ₹ 167.55000 | ₹ 837.75 |
| 10 | ₹ 128.64000 | ₹ 1,286.40 |
| 20 | ₹ 117.27000 | ₹ 2,345.40 |
| 40 | ₹ 105.90000 | ₹ 4,236.00 |
| 100 | ₹ 94.54000 | ₹ 9,454.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | VDRUS | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Peak AC Voltage Rating | 175 V | |
| Peak DC Voltage Limit | 225 V | |
| Min Clamp Voltage | 247.5 V | |
| Typical Varistor Voltage | 275 V | |
| Max Clamp Voltage | 302.5 V | |
| Surge Current Tolerance | 8 kA | |
| Stored Energy Capacity | 116J | |
| Electrical Circuit Count | 1 | |
| Capacitance at Specific Hz | 750 pF @ 1 kHz | |
| Ambient Temp Range | -40°C ~ 125°C (TA) | |
| Key Product Highlights | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | Disc 14mm |
Description
Delivers capacitance at a specified frequency of 750 pF @ 1 kHz. Is capable of withstanding surge current levels marked at 8 kA. Represents the energy capacity noted at 116J. Maximum signal delay 302.5 V at voltage for applications sensitive to timing. Maximum AC voltage 175 V for safe operation. Maximum DC voltage 225 V for safe electronic circuits. Mounting configuration Through Hole for structural stability. The total number of circuits stands at 1 for electrical or electronic setups. Temperature range -40°C ~ 125°C (TA) for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case Disc 14mm that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Classification series for the product or component VDRUS. Maximum varistor voltage 302.5 V for device protection. Minimum varistor voltage 247.5 V for device protection. Standard varistor voltage 275 V employed for circuit protection.
