Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | WE-VS | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Peak AC Voltage Rating | 6 V | |
| Peak DC Voltage Limit | 9 V | |
| Min Clamp Voltage | 9.6 V | |
| Typical Varistor Voltage | 12 V | |
| Max Clamp Voltage | 14.4 V | |
| Surge Current Tolerance | 20 A | |
| Stored Energy Capacity | 0.05J | |
| Electrical Circuit Count | 1 | |
| Capacitance at Specific Hz | 190 pF @ 1 kHz | |
| Ambient Temp Range | -40°C ~ 85°C (TA) | |
| Key Product Highlights | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount, MLCV | |
| Component Housing Style | 0402 (1005 Metric) |
Description
Delivers capacitance at a specified frequency of 190 pF @ 1 kHz. Is capable of withstanding surge current levels marked at 20 A. Represents the energy capacity noted at 0.05J. Maximum signal delay 14.4 V at voltage for applications sensitive to timing. Maximum AC voltage 6 V for safe operation. Maximum DC voltage 9 V for safe electronic circuits. Mounting configuration Surface Mount, MLCV for structural stability. The total number of circuits stands at 1 for electrical or electronic setups. Temperature range -40°C ~ 85°C (TA) for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 0402 (1005 Metric) that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Classification series for the product or component WE-VS. Maximum varistor voltage 14.4 V for device protection. Minimum varistor voltage 9.6 V for device protection. Standard varistor voltage 12 V employed for circuit protection.
