Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Spool | |
| Availability Status | Active | |
| Cord Construction Style | Multi-Conductor | |
| Wire Conductor Count | 4 | |
| AWG Wire Size | 22 AWG | |
| Multi-Filament Count | - | |
| Core Wire Alloy | - | |
| Cable Sheath Composition | Poly-Vinyl Chloride (PVC) | |
| Outer Jacket Thickness | 0.256" (6.50mm) | |
| EMI Shielding Design | Foil, Braid | |
| Linear Length Dimension | 820.2' (250.0m) | |
| Cable Outer Sheath Hue | Green | |
| Performance Rating Specs | UL Style 21694 | |
| Key Product Highlights | Oil Resistant, UV Resistant | |
| Electrical Voltage Rating | 80 V | |
| Ambient Temp Range | -40°C ~ 75°C | |
| Intended Usage Scenario | Ethernet | |
| Insulation Jacket Depth | - | |
| Wire Covering Layer | Polyethylene (PE) | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Classified under cable type Multi-Conductor for suitable use. Applies insulation for the conductor rated at Polyethylene (PE) to enhance safety and reliability. Equipped with features categorized as Oil Resistant, UV Resistant. Insulation jacket thickness of 0.256" (6.50mm) ensures sufficient protection. Jacket made from Poly-Vinyl Chloride (PVC) material for improved durability. Available in Green jacket color for easy recognition. Overall length 820.2' (250.0m) for size indication. The total number of conductors is 4 for wiring or cabling configurations. Temperature range -40°C ~ 75°C for environmental conditions impacting thermal efficiency. Type of housing Spool for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Criteria UL Style 21694 for electrical, mechanical, or environmental performance. Type of shield Foil, Braid for electromagnetic shielding. Application Ethernet for defined purpose or objective. The voltage specification 80 V for electrical parameters. Size of wire gauge 22 AWG according to electrical standards.
