Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Visual Hue | Red | |
| Light Wavelength nm | 621nm (Typ) | |
| Testing Current Value | 150mA | |
| Typical Forward Voltage | 2.25V | |
| Efficiency Lumens per Watt | 68 lm/W | |
| Maximum Amp Rating | - | |
| Lumens at Specified Amps/Temp | 24lm (20lm ~ 27lm) | |
| Testing Temperature Condition | - | |
| Display View Cone Degrees | 120° | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 4-PLCC | |
| Vendor Package Type | 4-PLCC | |
| Package Size Specs | 0.126" L x 0.118" W (3.20mm x 3.00mm) | |
| Maximum Mounted Height | 0.083" (2.10mm) |
Description
Offered in a shade referred to as Red to enhance the system's aesthetics. Assessed at current levels outlined by 150mA. Maximum installed height of 0.083" (2.10mm) for components affixed to the board. The lumens per watt 68 lm/W evaluated at the testing current to determine lighting efficiency. The luminous output 24lm (20lm ~ 27lm) at specified current and temperature for reliable performance. Mounting configuration Surface Mount for structural stability. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 4-PLCC that offers mechanical and thermal protection. Type of package 4-PLCC that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Details on package size 0.126" L x 0.118" W (3.20mm x 3.00mm) for electrical or mechanical components. Measurement dimensions 0.126" L x 0.118" W (3.20mm x 3.00mm) for component specifications. Supplier package type 4-PLCC for component selection. Viewing angle 120° for monitors. Common forward voltage Vf 2.25V for diode operation. Wavelength of light 621nm (Typ) for RF or optical devices.
