Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 12,994.00000 | ₹ 12,994.00 |
Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 13,020.44000 | ₹ 13,020.44 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | SSA-EB | |
| IC Encapsulation Type | Box | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount, Front | |
| Initialization Procedure | Twist | |
| Electrical Pathway | DPST-NO/NC | |
| Switch Operation Mode | On-Off, Off-On | |
| Key Product Highlights | - | |
| Ampere Capacity Rating | 2A (DC) | |
| AC Voltage Max | - | |
| DC Voltage Max | 24 V | |
| Mount Cutout Specs | Circular - 30.00mm Dia | |
| Lead Termination Type | Screw Terminal | |
| Dust Water Resistance Rating | IP65 - Dust Tight, Water Resistant | |
| Ambient Temp Range | -25°C ~ 55°C | |
| Standard Illumination Volts | - |
Description
Configured for circuit type described as DPST-NO/NC. Sets the ampere rating to 2A (DC). Rated with IP IP65 - Dust Tight, Water Resistant to safeguard against dust and moisture penetration. Mounting configuration Panel Mount, Front for structural stability. Temperature range -25°C ~ 55°C for environmental conditions impacting thermal efficiency. Type of housing Box for safeguarding or transporting components. Specifications of the cutout Circular - 30.00mm Dia for accurate mounting. Product status Active concerning availability and lifecycle. Installation guidelines Twist for operating the device. Classification series for the product or component SSA-EB. Modification in operation mode On-Off, Off-On for electrical optimization. Type of termination Screw Terminal for connector or device. The highest DC voltage specification 24 V for components.
