Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | M22EL | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount, Front | |
| Initialization Procedure | Pull | |
| Electrical Pathway | DPST-NO/NC | |
| Switch Operation Mode | On-Mom, Off-Mom | |
| Key Product Highlights | Illuminated (Red) | |
| Ampere Capacity Rating | 6A (AC), 3A (DC) | |
| AC Voltage Max | 230 V | |
| DC Voltage Max | 24 V | |
| Mount Cutout Specs | Circular - 22.30mm Dia | |
| Lead Termination Type | Screw Terminal | |
| Dust Water Resistance Rating | IP65 - Dust Tight, Water Resistant | |
| Ambient Temp Range | -25°C ~ 70°C | |
| Standard Illumination Volts | 30 VAC/DC |
Description
Configured for circuit type described as DPST-NO/NC. Sets the ampere rating to 6A (AC), 3A (DC). Equipped with features categorized as Illuminated (Red). Works at a standard voltage of 30 VAC/DC for illumination. Rated with IP IP65 - Dust Tight, Water Resistant to safeguard against dust and moisture penetration. Mounting configuration Panel Mount, Front for structural stability. Temperature range -25°C ~ 70°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Circular - 22.30mm Dia for accurate mounting. Product status Active concerning availability and lifecycle. Installation guidelines Pull for operating the device. Classification series for the product or component M22EL. Modification in operation mode On-Mom, Off-Mom for electrical optimization. Type of termination Screw Terminal for connector or device. The highest AC voltage specification 230 V for the device. The highest DC voltage specification 24 V for components.
