Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 21000 | ₹ 38.26000 | ₹ 8,03,460.00 |
| 15000 | ₹ 38.57000 | ₹ 5,78,550.00 |
| 9000 | ₹ 39.10000 | ₹ 3,51,900.00 |
| 6000 | ₹ 39.58000 | ₹ 2,37,480.00 |
| 3000 | ₹ 40.54000 | ₹ 1,21,620.00 |
| 1000 | ₹ 44.06000 | ₹ 44,060.00 |
| 500 | ₹ 44.08000 | ₹ 22,040.00 |
| 250 | ₹ 46.00000 | ₹ 11,500.00 |
| 100 | ₹ 49.19000 | ₹ 4,919.00 |
| 25 | ₹ 55.89000 | ₹ 1,397.25 |
| 10 | ₹ 61.99000 | ₹ 619.90 |
| 1 | ₹ 85.80000 | ₹ 85.80 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Active | |
| Circuit Switching Type | SPDT | |
| Signal Mux/Demux Channels | 2:1 | |
| Electrical Circuit Count | 2 | |
| Maximum On Resistance | 500mOhm | |
| Inter-Channel Resistance Match | 60mOhm | |
| Single Positive Supply | 1.65V ~ 4.3V | |
| Dual Symmetric Supply | - | |
| Max On/Off Switching Time | 78ns, 58ns | |
| 3dB Bandwidth | 50MHz | |
| Charge Transfer Effect | - | |
| Off-State Channel Capacitance | 55pF | |
| Max Off-State Leakage | 2nA | |
| Signal Interference Level | -70dB @ 100kHz | |
| Ambient Temp Range | -40°C ~ 85°C (TA) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 10-UFQFN | |
| Vendor Package Type | 10-miniQFN (1.4x1.8) |
Description
Delivers a -3dB bandwidth of 50MHz to maintain reliable signal quality. Offers off-state channel capacitance of 55pF. Ensures ΔRon alignment accuracy defined at 60mOhm. Minimizes crosstalk with a level of -70dB @ 100kHz for improved signal quality. Highlights the maximum off-state leakage (IS(off)) rated at 2nA. Mounting configuration Surface Mount for structural stability. Mux/demux pathway 2:1 for signal control. The total number of circuits stands at 2 for electrical or electronic setups. Resistance during the on-state 500mOhm for effective conduction. Peak resistance in the on-state 500mOhm for electrical efficiency. Temperature range -40°C ~ 85°C (TA) for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 10-UFQFN that offers mechanical and thermal protection. Type of package 10-miniQFN (1.4x1.8) that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Supplier package type 10-miniQFN (1.4x1.8) for component selection. Circuit switch SPDT for functional operations. Maximum on/off switching duration Ton/Toff 78ns, 58ns for timing accuracy. Single voltage supply for electronic devices at V+ 1.65V ~ 4.3V.
