Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tube | |
| Availability Status | Obsolete | |
| Stepper Motor Variant | - | |
| AC/DC Motor Classification | Brushed DC | |
| Primary Function Mode | Driver - Fully Integrated, Control and Power Stage | |
| Output Setup Options | Half Bridge (2) | |
| User Interface Type | PWM, Serial | |
| Core Technology Platform | Bi-CMOS | |
| Precision Step Size | - | |
| Intended Uses | General Purpose | |
| Output Delivery Amps | 4.5A | |
| Power Supply Voltage | 10V ~ 27V | |
| Output Load Voltage | 10V ~ 27V | |
| Ambient Temp Range | -20°C ~ 85°C (TA) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 25-SSIP Formed Leads | |
| Vendor Package Type | 25-HZIP |
Description
Perfectly designed for situations involving General Purpose. Yields output current measured at 4.5A. Engineered with Driver - Fully Integrated, Control and Power Stage features for versatile component usage. Designed for PWM, Serial ease of use and user interaction. Classification of AC/DC motor Brushed DC for power compatibility. Mounting configuration Through Hole for structural stability. Temperature range -20°C ~ 85°C (TA) for environmental conditions impacting thermal efficiency. Preferences Half Bridge (2) for establishing system output configurations. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case 25-SSIP Formed Leads that offers mechanical and thermal protection. Type of package 25-HZIP that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Supplier package type 25-HZIP for component selection. Voltage requirement 10V ~ 27V for electrical specifications. The primary technology platform Bi-CMOS linked to the product category. Load voltage 10V ~ 27V required for devices. Voltage supply 10V ~ 27V for device operation.
