Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tray | |
| Availability Status | Obsolete | |
| Electrical Switch Category | General Purpose | |
| Signal Output Quantity | 12 (4 High Side, 8 Low Side) | |
| Input to Output Ratio | - | |
| Output Setup Options | High Side or Low Side | |
| Exit Signal Category | N-Channel | |
| User Interface Type | SPI | |
| Output Load Voltage | 6V ~ 27V | |
| Core Supply Voltage | 4.5V ~ 5.5V | |
| Peak Output Current | - | |
| Typical On Resistance | 10mOhm, 40mOhm, 600mOhm | |
| Entry Signal Category | - | |
| Key Product Highlights | Watchdog Timer | |
| Error Safeguard Features | Current Limiting (Fixed), Open Load Detect, Over Voltage | |
| Ambient Temp Range | -40°C ~ 150°C (TJ) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Vendor Package Type | 64-PQFP (14x14) | |
| Component Housing Style | 64-PowerBQFP |
Description
Features fault protection capabilities quantified at Current Limiting (Fixed), Open Load Detect, Over Voltage. Equipped with features categorized as Watchdog Timer. Designed for SPI ease of use and user interaction. Mounting configuration Surface Mount for structural stability. Overall outputs 12 (4 High Side, 8 Low Side) for device connections. Resistance during the on-state 10mOhm, 40mOhm, 600mOhm for effective conduction. Temperature range -40°C ~ 150°C (TJ) for environmental conditions impacting thermal efficiency. Preferences High Side or Low Side for establishing system output configurations. Type N-Channel for ensuring compatibility with output systems. Type of housing Tray for safeguarding or transporting components. Style of the enclosure/case 64-PowerBQFP that offers mechanical and thermal protection. Type of package 64-PQFP (14x14) that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Mean Rds(on) 10mOhm, 40mOhm, 600mOhm for MOSFET functionality. Supplier package type 64-PQFP (14x14) for component selection. Voltage requirement 4.5V ~ 5.5V for electrical specifications. Classification of switch General Purpose for equipment selection. Load voltage 6V ~ 27V required for devices. Vcc/Vdd voltage supply 4.5V ~ 5.5V for electronic devices.
