Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | OPIC™ | |
| IC Encapsulation Type | Tube | |
| Availability Status | Obsolete | |
| Core Technology Platform | Optical Coupling | |
| Audio/Video Channel Count | 1 | |
| Isolation Barrier Voltage | 4000Vrms | |
| Minimum Surge Tolerance | 1.5kV/µs | |
| Max Low-to-High/High-to-Low Delay | 2µs, 2µs | |
| Max Pulse Skew | - | |
| Typical Edge Transition Time | 200ns, 200ns | |
| High/Low Logic Current | - | |
| Peak Delivery Current | 400mA | |
| Typical Forward Voltage | 1.2V | |
| Max Forward DC Current | 25 mA | |
| Output Supply Voltage | 15V ~ 30V | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Ambient Temp Range | -25°C ~ 80°C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 14-SOIC (0.256", 6.50mm Width) | |
| Vendor Package Type | 14-SMT | |
| Certification Body | UR |
Description
