Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | N1200 | |
| IC Encapsulation Type | Box | |
| Availability Status | Active | |
| Device Type Classification | Process, Temperature Controller (RTD, Voltage, Current, Type B, E, J, K, N, R, S, T) | |
| Acceptable Input Limits | -270°C ~ 1800°C, -454°F ~ 3272°F, 0 ~ 20mA, 0 ~ 10VDC, 0 ~ 50mV | |
| Exit Signal Category | Analog, Relay (2), Voltage (External SSR) | |
| Operation Technique | On/Off, Proportional (PID) | |
| Data Exchange Protocol | USB | |
| Row Character Limit | 4, 4 | |
| Screen Technology Type | LED - Dual Color Characters | |
| Character Vertical Size | 0.394" (10.00mm) | |
| Power Supply Voltage | 100 ~ 240VAC/VDC | |
| Mount Cutout Specs | Square - 45.50mm x 45.50mm | |
| Attachment Mounting Style | Panel Mount | |
| Lead Termination Type | Screw Terminal | |
| Dust Water Resistance Rating | IP65 - Front, IP20 Rear | |
| Key Product Highlights | USB Configurable, Ramp and Soak, Auto-Adaptive, Auto-Tuning, Sensor Fault Detection, Alarm Signaling |
Description
Supports communication protocols specified as USB for device interoperability. Implements a control method specified as On/Off, Proportional (PID). Emphasizes character height recorded at 0.394" (10.00mm). Features a display type recognized as LED - Dual Color Characters. Equipped with features categorized as USB Configurable, Ramp and Soak, Auto-Adaptive, Auto-Tuning, Sensor Fault Detection, Alarm Signaling. Rated with IP IP65 - Front, IP20 Rear to safeguard against dust and moisture penetration. The input limits of -270°C ~ 1800°C, -454°F ~ 3272°F, 0 ~ 20mA, 0 ~ 10VDC, 0 ~ 50mV guarantee compatibility with different sources. Mounting configuration Panel Mount for structural stability. The maximum number of characters allowed per row is 4, 4 for layout purposes. Type Analog, Relay (2), Voltage (External SSR) for ensuring compatibility with output systems. Type of housing Box for safeguarding or transporting components. Specifications of the cutout Square - 45.50mm x 45.50mm for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component N1200. Voltage requirement 100 ~ 240VAC/VDC for electrical specifications. Type of termination Screw Terminal for connector or device. Type classification Process, Temperature Controller (RTD, Voltage, Current, Type B, E, J, K, N, R, S, T) for specifications. Voltage supply 100 ~ 240VAC/VDC for device operation.
