Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | E5GN | |
| IC Encapsulation Type | Box | |
| Availability Status | Obsolete | |
| Device Type Classification | Temperature Controller (RTD, Type B, E, J, K, L, N, PLII, R, S, T, U, W) | |
| Acceptable Input Limits | -200°C ~ 2300°C, 0 ~ 50mV | |
| Exit Signal Category | Relay (2) | |
| Operation Technique | On/Off, Proportional (PID) | |
| Data Exchange Protocol | - | |
| Row Character Limit | 4, 4 | |
| Screen Technology Type | LCD - Dual Color Characters, Backlight | |
| Character Vertical Size | 0.295" (7.50mm), 0.142" (3.60mm) | |
| Power Supply Voltage | 24VAC/DC | |
| Mount Cutout Specs | Rectangular - 45.00mm x 22.20mm | |
| Attachment Mounting Style | Panel Mount | |
| Lead Termination Type | Screw Terminal | |
| Dust Water Resistance Rating | IP66 - Dust Tight, Water Resistant | |
| Key Product Highlights | - |
Description
Implements a control method specified as On/Off, Proportional (PID). Emphasizes character height recorded at 0.295" (7.50mm), 0.142" (3.60mm). Features a display type recognized as LCD - Dual Color Characters, Backlight. Rated with IP IP66 - Dust Tight, Water Resistant to safeguard against dust and moisture penetration. The input limits of -200°C ~ 2300°C, 0 ~ 50mV guarantee compatibility with different sources. Mounting configuration Panel Mount for structural stability. The maximum number of characters allowed per row is 4, 4 for layout purposes. Type Relay (2) for ensuring compatibility with output systems. Type of housing Box for safeguarding or transporting components. Specifications of the cutout Rectangular - 45.00mm x 22.20mm for accurate mounting. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component E5GN. Voltage requirement 24VAC/DC for electrical specifications. Type of termination Screw Terminal for connector or device. Type classification Temperature Controller (RTD, Type B, E, J, K, L, N, PLII, R, S, T, U, W) for specifications. Voltage supply 24VAC/DC for device operation.
