Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Device Type Classification | Laminated Core | |
| Input Primary Voltage | 120V | |
| Loaded Secondary Volts | 24V | |
| Peak Output Current | - | |
| Input Coil Turns | Single | |
| Output Coil Turns | Single | |
| Midpoint Connection | No | |
| Maximum Power Handling | 75VA | |
| Attachment Mounting Style | Chassis Mount | |
| Lead Termination Type | Solder, Quick Connect | |
| Package Size Specs | 76.20mm L x 63.50mm W | |
| Maximum Mounted Height | - | |
| Isolation Barrier Voltage | - | |
| Product Weight Grams | 2.4 lbs (1.1 kg) |
Description
Includes a center tap characterized as No for flexible setup. Mounting configuration Chassis Mount for structural stability. Type of housing Bulk for safeguarding or transporting components. Maximum power capability 75VA for safeguarding the device. Primary winding(s) Single for coil or transformer setup. Product status Obsolete concerning availability and lifecycle. Supplementary turns Single for transformers or coils. Details on package size 76.20mm L x 63.50mm W for electrical or mechanical components. Measurement dimensions 76.20mm L x 63.50mm W for component specifications. Type of termination Solder, Quick Connect for connector or device. Type classification Laminated Core for specifications. The primary voltage input 120V for transformers or circuits. Secondary voltage 24V when fully loaded. Weight 2.4 lbs (1.1 kg) for product specifications.
