Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | WE-GDT | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Active | |
| Voltage Transformer Design | Gate Drive | |
| Coil Inductance Value | 750µH | |
| Volt-Second Product | 102VµS | |
| Transformer Turn Ratio | 1:1 | |
| Attachment Mounting Style | Surface Mount | |
| Package Size Specs | 0.413" L x 0.413" W (10.50mm x 10.50mm) | |
| Maximum Mounted Height | 0.433" (11.00mm) | |
| Ambient Temp Range | -40°C ~ 125°C | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Includes ET volt-time rating quantified at 102VµS. Maximum installed height of 0.433" (11.00mm) for components affixed to the board. Provides 750µH inductance for circuit tuning and filtering. Mounting configuration Surface Mount for structural stability. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Classification series for the product or component WE-GDT. Details on package size 0.413" L x 0.413" W (10.50mm x 10.50mm) for electrical or mechanical components. Measurement dimensions 0.413" L x 0.413" W (10.50mm x 10.50mm) for component specifications. Design of transformer Gate Drive for electrical conversion. Turns ratio from primary to secondary 1:1 in transformers.
