Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Spool | |
| Availability Status | Active | |
| Design Style Variant | Multiple Fibers | |
| Device Type Classification | Multimode | |
| Linear Length Dimension | 1000.0' (304.8m) | |
| Central Fiber Width | 900µm | |
| Outer Layer Width | 125µm | |
| Cable Sheath Composition | Poly-Vinyl Chloride (PVC) | |
| Outer Jacket Thickness | - | |
| Pull Strength Rating | 30.39kg | |
| Typical Signal Loss | 3.0db/km | |
| Core Light Bend Index | 1.46 | |
| Cladding Light Bend Index | 1.45 | |
| Cable Outer Sheath Hue | Aqua | |
| Minimum Flex Curve | 45mm | |
| Performance Rating Specs | OFNP | |
| Key Product Highlights | 6 Fibers, Armored |
Description
Provides average attenuation of 3.0db/km for steady signal decrease. Supports a bending radius of 45mm enabling flexible routing possibilities. Has a cladding diameter of 125µm to maintain fiber consistency. Measures the diameter of the core at 900µm. Equipped with features categorized as 6 Fibers, Armored. Jacket made from Poly-Vinyl Chloride (PVC) material for improved durability. Available in Aqua jacket color for easy recognition. Overall length 1000.0' (304.8m) for size indication. Type of housing Spool for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Criteria OFNP for electrical, mechanical, or environmental performance. Refractive index 1.45 of the cladding that affects optical fiber functionality. Refractive index 1.46 of the core that influences optical fiber performance. Style variant Multiple Fibers for design or arrangement. Tensile rating 30.39kg for material durability. Type classification Multimode for specifications.
