Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | WSEN-PDUS | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Active | |
| Intended Uses | Board Mount | |
| Pressure Sensing Mode | Differential | |
| Working Pressure Limit | -0.15PSI ~ 0.15PSI (-1kPa ~ 1kPa) | |
| Exit Signal Category | Analog Voltage, I2C | |
| Signal Output Format | 15 b | |
| Precision Level | ±0.75% | |
| Power Supply Voltage | 3V ~ 3.6V | |
| Network Port Dimension | Male - 0.107" (2.72mm) Tube, Dual | |
| Interface Port Design | Barbed | |
| Key Product Highlights | Temperature Compensated | |
| Lead Termination Type | - | |
| Peak Pressure Tolerance | 1.45PSI (10kPa) | |
| Ambient Temp Range | -25°C ~ 85°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 8-SMD, No Lead, Dual Ports, Same Side | |
| Vendor Package Type | - |
Description
Delivers measurement precision rated at ±0.75% for reliable results. Perfectly designed for situations involving Board Mount. Equipped with features categorized as Temperature Compensated. Maximum pressure 1.45PSI (10kPa) for hydraulic or pneumatic applications. Mounting configuration Surface Mount for structural stability. Maximum pressure threshold -0.15PSI ~ 0.15PSI (-1kPa ~ 1kPa) for pneumatic or hydraulic operations. Temperature range -25°C ~ 85°C for environmental conditions impacting thermal efficiency. Output format 15 b for electrical or signal communication. Type Analog Voltage, I2C for ensuring compatibility with output systems. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 8-SMD, No Lead, Dual Ports, Same Side that offers mechanical and thermal protection. The Male - 0.107" (2.72mm) Tube, Dual measurement of the port for mechanical or fluid compatibility. The Barbed configuration of the port for connector or interface categorization. Category of pressure Differential for operational or measurement purposes. Product status Active concerning availability and lifecycle. Classification series for the product or component WSEN-PDUS. Voltage requirement 3V ~ 3.6V for electrical specifications. Voltage supply 3V ~ 3.6V for device operation.
