Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 100 | ₹ 875.09000 | ₹ 87,509.00 |
| 40 | ₹ 898.92000 | ₹ 35,956.80 |
| 20 | ₹ 953.35000 | ₹ 19,067.00 |
| 1 | ₹ 1,234.26000 | ₹ 1,234.26 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Amorton | |
| IC Encapsulation Type | Box | |
| Availability Status | Last Time Buy | |
| Maximum Watt Output | 189 mW | |
| Current at Maximum Power Point | 41.9 mA | |
| Voltage at Max Power Point | 4.5 V | |
| Short Circuit Current Rating | - | |
| Device Type Classification | Amorphous | |
| Open Circuit Voltage | 6.8 V | |
| Ambient Temp Range | -10°C ~ 60°C | |
| Component Housing Style | Cells | |
| Package Size Specs | 2.272" L x 2.169" W x 0.079" H (57.70mm x 55.10mm x 2.00mm) |
Description
Delivers current at Pmpp indicated as 41.9 mA. Temperature range -10°C ~ 60°C for environmental conditions impacting thermal efficiency. Type of housing Box for safeguarding or transporting components. Style of the enclosure/case Cells that offers mechanical and thermal protection. Ultimate power threshold 189 mW for safe operation. Product status Last Time Buy concerning availability and lifecycle. Classification series for the product or component Amorton. Details on package size 2.272" L x 2.169" W x 0.079" H (57.70mm x 55.10mm x 2.00mm) for electrical or mechanical components. Measurement dimensions 2.272" L x 2.169" W x 0.079" H (57.70mm x 55.10mm x 2.00mm) for component specifications. Type classification Amorphous for specifications. The voltage 6.8 V under open-circuit conditions for device assessment. Voltage at the maximum power point 4.5 V for solar or energy systems.
