Stock:
Distributor: 111
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 8400 | ₹ 66.37000 | ₹ 5,57,508.00 |
| 5250 | ₹ 66.70000 | ₹ 3,50,175.00 |
| 3150 | ₹ 68.19000 | ₹ 2,14,798.50 |
| 1050 | ₹ 69.85000 | ₹ 73,342.50 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 204 | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Active | |
| Electrical Pathway | SPST | |
| Switch Position Options | 4 | |
| Ampere Capacity Rating | 50mA | |
| Max Voltage Specification | 24VDC | |
| Activator Mechanism Type | Slide (Standard) | |
| Activator Position Level | Raised | |
| Pin Alloy Composition | - | |
| Pin Surface Treatment | Gold | |
| PCB Clearance Height | 0.394" (10.00mm) | |
| Attachment Mounting Style | Surface Mount | |
| Lead Termination Type | Gull Wing | |
| Component Spacing Distance | 0.100" (2.54mm), Full | |
| Cleanable Feature | Yes | |
| Key Product Highlights | Epoxy Sealed Terminals, Tape Seal | |
| Ambient Temp Range | -55°C ~ 85°C |
Description
Facilitates actuation levels defined at Raised for accurate feedback. Incorporates a Slide (Standard) actuator type to fulfill the desired function. Configured for circuit type described as SPST. Includes contact finish plated at Gold to improve conductivity. Sets the ampere rating to 50mA. Equipped with features categorized as Epoxy Sealed Terminals, Tape Seal. Maintains a height of 0.394" (10.00mm) above the board to accommodate assembly and clearance requirements. Mounting configuration Surface Mount for structural stability. Overall number of positions 4 for switches or mechanical components. Temperature range -55°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Distance 0.100" (2.54mm), Full for arranging components or aligning connectors. Product status Active concerning availability and lifecycle. Classification series for the product or component 204. Type of termination Gull Wing for connector or device. Voltage specification 24VDC for electronic devices. A feature that is capable of being cleaned Yes for the device or material.
