Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | SWK12 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Electrical Pathway | SPST | |
| Switch Position Options | 2 | |
| Switch Operation Mode | On-Off | |
| Switch Activation Sequence | Non-Shorting (BBM) | |
| Ampere Capacity Rating | 5A (AC), 15A (DC) | |
| AC Voltage Max | 115 V | |
| DC Voltage Max | 24 V | |
| Activator Mechanism Type | Flat Key | |
| Key Extraction Slots | 1 only | |
| Switch Throw Angle | 90° | |
| Pin Alloy Composition | Silver (Ag) | |
| Pin Surface Treatment | - | |
| Attachment Mounting Style | Panel Mount | |
| Lead Termination Type | Screw Terminal | |
| Mount Cutout Specs | Circular - 19.20mm Dia | |
| Key Product Highlights | - | |
| Ambient Temp Range | -30°C ~ 85°C |
Description
Incorporates a Flat Key actuator type to fulfill the desired function. Delivers a throw angle of 90° for efficient switching operation. Configured for circuit type described as SPST. Constructed from the contact material known as Silver (Ag). Displays the contact timing characteristics defined as Non-Shorting (BBM). Sets the ampere rating to 5A (AC), 15A (DC). Supports 1 only removable key locations for flexible operation. Mounting configuration Panel Mount for structural stability. Overall number of positions 2 for switches or mechanical components. Temperature range -30°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Circular - 19.20mm Dia for accurate mounting. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component SWK12. Modification in operation mode On-Off for electrical optimization. Type of termination Screw Terminal for connector or device. The highest AC voltage specification 115 V for the device. The highest DC voltage specification 24 V for components.
