Description

Incorporates a Round (Pin Plunger) actuator type to fulfill the desired function. Configured for circuit type described as SPST-NO. Sets the ampere rating to 11A (AC), 500mA (DC). Offers a measurement of the differential travel at 0.010" (0.25mm). Indicates electrical lifespan evaluated at 100,000 Cycles. Mechanical strength 10,000,000 Cycles cycles for durability. Mounting configuration Chassis Mount for structural stability. Pressure applied 75gf for ergonomic or mechanical operations. Position configuration 0.579" (14.7mm) for correct device alignment. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Additional travel distance 0.050" (1.27mm) for mechanical safety and longevity. Type of housing Bulk for safeguarding or transporting components. Initial distance 0.047" (1.2mm) for mechanical control or switch activation. Product status Active concerning availability and lifecycle. Force needed 10gf to activate mechanical or electrical switches. Classification series for the product or component V7. Modification in operation mode Off-Mom for electrical optimization. Type of termination Quick Connect - 0.187" (4.7mm) for connector or device. The highest AC voltage specification 125 V for the device. The highest DC voltage specification 125 V for components.
