Stock:
Distributor: 58
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 5000 | ₹ 62.51000 | ₹ 3,12,550.00 |
| 2500 | ₹ 75.01000 | ₹ 1,87,525.00 |
| 1250 | ₹ 87.51000 | ₹ 1,09,387.50 |
| 125 | ₹ 98.87000 | ₹ 12,358.75 |
Stock:
Distributor: 129
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 37500 | ₹ 77.88000 | ₹ 29,20,500.00 |
| 18750 | ₹ 79.87000 | ₹ 14,97,562.50 |
| 7500 | ₹ 81.98000 | ₹ 6,14,850.00 |
| 3750 | ₹ 84.19000 | ₹ 3,15,712.50 |
| 2250 | ₹ 85.34000 | ₹ 1,92,015.00 |
| 1500 | ₹ 86.53000 | ₹ 1,29,795.00 |
| 750 | ₹ 87.75000 | ₹ 65,812.50 |
Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 168.21000 | ₹ 168.21 |
| 10 | ₹ 127.27000 | ₹ 1,272.70 |
| 25 | ₹ 125.49000 | ₹ 3,137.25 |
| 50 | ₹ 113.03000 | ₹ 5,651.50 |
| 100 | ₹ 103.24000 | ₹ 10,324.00 |
| 250 | ₹ 102.35000 | ₹ 25,587.50 |
| 750 | ₹ 101.46000 | ₹ 76,095.00 |
| 5250 | ₹ 89.00000 | ₹ 4,67,250.00 |
Stock:
Distributor: 113
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 25 | ₹ 199.73000 | ₹ 4,993.25 |
| 100 | ₹ 186.03000 | ₹ 18,603.00 |
| 250 | ₹ 176.93000 | ₹ 44,232.50 |
| 750 | ₹ 165.97000 | ₹ 1,24,477.50 |
| 1500 | ₹ 159.11000 | ₹ 2,38,665.00 |
| 3000 | ₹ 152.26000 | ₹ 4,56,780.00 |
| 5250 | ₹ 125.47000 | ₹ 6,58,717.50 |
| 7500 | ₹ 122.48000 | ₹ 9,18,600.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | D2F | |
| IC Encapsulation Type | Tray | |
| Availability Status | Active | |
| Electrical Pathway | SPDT | |
| Switch Operation Mode | On-Mom | |
| Ampere Capacity Rating | 100mA (DC) | |
| AC Voltage Max | - | |
| DC Voltage Max | 30 V | |
| Activator Mechanism Type | Lever, Simulated Roller | |
| Attachment Mounting Style | Through Hole | |
| Lead Termination Type | PC Pin | |
| Dust Water Resistance Rating | IP40 | |
| Key Product Highlights | - | |
| Activation Pressure Required | 40gf | |
| Detachment Pressure | 2.039gf | |
| Functional Position Setting | 0.335" (8.5mm) | |
| Initial Travel Distance | - | |
| Switch Travel Difference | 0.018" (0.45mm) | |
| Excess Travel Distance | 0.020" (0.5mm) | |
| Physical Durability Cycles | 1,000,000 Cycles | |
| Cycle Durability Rating | 100,000 Cycles | |
| Ambient Temp Range | -40°C ~ 85°C |
Description
Incorporates a Lever, Simulated Roller actuator type to fulfill the desired function. Configured for circuit type described as SPDT. Sets the ampere rating to 100mA (DC). Offers a measurement of the differential travel at 0.018" (0.45mm). Indicates electrical lifespan evaluated at 100,000 Cycles. Rated with IP IP40 to safeguard against dust and moisture penetration. Mechanical strength 1,000,000 Cycles cycles for durability. Mounting configuration Through Hole for structural stability. Pressure applied 40gf for ergonomic or mechanical operations. Position configuration 0.335" (8.5mm) for correct device alignment. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Additional travel distance 0.020" (0.5mm) for mechanical safety and longevity. Type of housing Tray for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Force needed 2.039gf to activate mechanical or electrical switches. Classification series for the product or component D2F. Modification in operation mode On-Mom for electrical optimization. Type of termination PC Pin for connector or device. The highest DC voltage specification 30 V for components.
