Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 9,256.00000 | ₹ 9,256.00 |
Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 9,256.00000 | ₹ 9,256.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | K30 | |
| IC Encapsulation Type | Box | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount, Front | |
| Device Type Classification | Standard, Illuminated | |
| Electrical Pathway | SPST-NO | |
| Switch Operation Mode | Off-Mom | |
| Ampere Capacity Rating | 150mA (DC) | |
| AC Voltage Max | - | |
| DC Voltage Max | 30 V | |
| Activator Mechanism Type | Round, Button, Domed | |
| Activator Label Indicator | No Marking | |
| Activator Cap Shade | - | |
| LED Illumination Shades | LED, Green/Red | |
| Standard Illumination Volts | 30 VDC | |
| Lead Termination Type | Connector | |
| Dust Water Resistance Rating | IP67 - Dust Tight, Waterproof | |
| Key Product Highlights | - | |
| Mount Cutout Specs | Circular - 22.00mm Dia | |
| Ambient Temp Range | -40°C ~ 50°C |
Description
Features labels marked as No Marking for easy identification. Incorporates a Round, Button, Domed actuator type to fulfill the desired function. Configured for circuit type described as SPST-NO. Sets the ampere rating to 150mA (DC). Includes LED, Green/Red colored LEDs for effective signaling. Works at a standard voltage of 30 VDC for illumination. Rated with IP IP67 - Dust Tight, Waterproof to safeguard against dust and moisture penetration. Mounting configuration Panel Mount, Front for structural stability. Temperature range -40°C ~ 50°C for environmental conditions impacting thermal efficiency. Type of housing Box for safeguarding or transporting components. Specifications of the cutout Circular - 22.00mm Dia for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component K30. Modification in operation mode Off-Mom for electrical optimization. Type of termination Connector for connector or device. Type classification Standard, Illuminated for specifications. The highest DC voltage specification 30 V for components.
