Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 554 | |
| IC Encapsulation Type | Bulk | |
| Attachment Mounting Style | Panel Mount, Snap-In | |
| Device Type Classification | Standard, Illuminated | |
| Electrical Pathway | DPDT | |
| Switch Operation Mode | On-On | |
| Ampere Capacity Rating | 7A (AC/DC) | |
| AC Voltage Max | 125 V | |
| DC Voltage Max | 30 V | |
| Activator Mechanism Type | Plunger for Cap | |
| Activator Label Indicator | No Marking | |
| Activator Cap Shade | - | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Lead Termination Type | Solder, Quick Connect - 0.110" (2.8mm) | |
| Dust Water Resistance Rating | - | |
| Key Product Highlights | - | |
| Mount Cutout Specs | Square - 22.35mm x 22.35mm | |
| Ambient Temp Range | - |
Description
Features labels marked as No Marking for easy identification. Incorporates a Plunger for Cap actuator type to fulfill the desired function. Configured for circuit type described as DPDT. Sets the ampere rating to 7A (AC/DC). Mounting configuration Panel Mount, Snap-In for structural stability. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Square - 22.35mm x 22.35mm for accurate mounting. Classification series for the product or component 554. Modification in operation mode On-On for electrical optimization. Type of termination Solder, Quick Connect - 0.110" (2.8mm) for connector or device. Type classification Standard, Illuminated for specifications. The highest AC voltage specification 125 V for the device. The highest DC voltage specification 30 V for components.
